输入
input Voltage ·23-26VDC
Input Frequency ·
Input Current ·7.2A max at 24Vdc, full load
Inrush Current ·
Input Protection ·24VDC：Internal fuse Protection

输出
Output Voltage ·V: 54VDC
Output
Voltage Trim
·V: 57VDCmax
Initial Set Accuracy ·NOR
Rated Load ·120±3mA * 24Channel
Open Lamp
Protection
· Shutdown & ERR Signal:an active-high
TTL-compatible

常规
Efficiency ·Up to 95% at rating load
Isolation ·NOR
Control Signals ·VBLON
MTBF ·100000H or more
Environmental
Operating
Temperature
·0°C to +50 °C
Cooling ·Forced air cooling
Operating Humidity ·20%~85% RH, non-condensing
Storage Temperature ·-20 °C ~ +70 °C Non binding
Operating Altitude ·3000 m max
Shock ·Operating 5g, No Operating 30g,
X, Y, Z in each direction, each of the 3 back
Vibration ·3mm, 5HZ to 20KHz, 3axes
