输入电压               · 85-110 VAC

输入频率               · 47-63 Hz

输入电流               · 2.9 A typical at 85 VAC, full load

浪涌电流               · 30 A max at 110 VAC, cold start at 25 °C

输入保护               · Internal T5.0 A/250 V fuse in line

and neutral

输出

输出电压              · V1: -24V V2: 5 VDC

输出电流              · V1: 4A V2: 8A

输出电压修正         · ±3% (see Mechanical Details)

初始设置精度         · ±0.5% V1, ±0.5% V2

启动延迟              · 1S  typical

启动上升时间          · 0.2S max

保持时间          · 20mS min at 100 VAC

常规：

功效                   . Up to 80%

隔离                  · 1200 VAC Input to Output

  . 1200 VAC Input to Ground

MTBF                 · 60000 Hrs or more  at35 °C.

环境

工作温度             · 0 °Cto +50 °C

冷却                 · Convection cooled

工作湿度             ·15% to 85% RH

储存温度             ·-10 °Cto +75 °C

工作高度             ·3000 m

振动                 ·3 mm, 5 Hz to 20 kHz, 3 axes
