输入 输入电压 · 90-285 VAC 输入频率 · 47-63 Hz 输入电源 ·18.6Atypical at 110 VAC, full load 30 A typical at 230 VAC, full load 浪涌电源 ·30 Amax at 230 VAC, cold start at25 °C 功率因数 · >0.99 输入保护 · Internal T15.0 A/250 V fuse in line and neutral 输出 输出电压 · 43-58 VDC 输出电流 ·90A( 30A module parallel) 初始设置精度 · ±0.5% 最小负载 · No minimum load required 启动延迟 ·5S typical 启动上升时间 · 3S typical 保持时间 · 10 mS min at 230VAC |
常规 功效 . Up to 92% 隔离 · 3000 VAC Input to Output 2 x MOPP, 1500 VAC Input to Ground 1 x MOPP, 500 VDC Output to Ground 1 x MOPP 信号 · Power Fail Inhibit, 5 V Standby MTBF · 100000 Hrs to MIL-HDBK-217Fat 25 °C
环境 工作温度 ·-20 °Cto +70 °Cderate linearly from +50 °Cat 2.5%/˚C to 50% load at +70 °C. See derating curve & longform datasheet 冷却 · Convection cooled 工作湿度 · 95% RH, non-condensing 储存温度 ·-40 °Cto +85 °C 工作高度 ·3000 m 震动 ·30 gpk, half sine, 6 axes 振动 ·2 grms, 5 Hz to 500 kHz, 3 axes |
